YT-450CNC CNC Surface Grinder

  • CNC surface grinder with high-precision closed-loop control system
  • Automatic grinding cycles: rough grinding / fine grinding / spark-out
  • Suitable for mold making, precision parts, die processing
  • XYZ axis full servo control with micron-level accuracy (±0.002mm)
  • Intelligent parameter programming, no coding experience required
  • Automatic wheel dressing & compensation system for stable accuracy
  • Heavy-duty cast iron base for high rigidity and long-term stability
  • Ideal alternative to hydraulic surface grinder & manual grinding machine
Request a Quote
YUTON YT-450CNC rotary surface grinder with automated spindle and table control for precision circular part finishing

Technical Parameters Summary

YUTON YT-450CNC rotary surface grinder with automated spindle and table control for precision circular part finishing
YT-450CNC CNC Surface Grinder

Specification Item Unit YT-450CNC
Working Capacity Table Working Area mm 150×450
Max. Longitudinal Travel mm 460
Max. Cross Travel mm 160
Max. Distance from Spindle to Table mm 50-300
Max. Table Load kg 100
Table Longitudinal Travel Min. Longitudinal Feed Increment mm 0.001/0.01
Longitudinal Feed Speed mm/min 0~15000
Cross Structure Min. Cross Feed Increment mm 0.001/0.01
Cross Feed Speed mm/min 0~400
Vertical Structure Min. Vertical Feed Increment mm 0.001/0.01
Vertical Feed Speed mm/min 0~400
Spindle Spindle Motor KW 1.5hp/2.0hp
Max. Spindle Speed R.P.M 1800/3600
Motor Longitudinal Servo Motor W 750
Cross Servo Motor W 750
Vertical Servo Motor W 750
Water Flushing Motor W 120
Dimensions / Weight Machine Height mm 1600
Footprint mm 2104×1150
Net Weight (Approx.) kg 1100

YT-450CNC CNC Surface Grinder Overview

  • The YT-450CNC CNC Surface Grinding Machine is a high-precision automatic grinder designed for modern mold manufacturing and precision machining industries. It combines CNC intelligent control + hydraulic-style stable grinding structure, making it an upgraded alternative to traditional manual and hydraulic surface grinders.
  • This model is widely used in mold making, metal parts finishing, tooling, and high-accuracy surface processing, especially for customers requiring stable mass production and micron-level accuracy.

Core Features

1. CNC Intelligent Grinding System

  • No-programming parameter input system (easy operation)
  • Multi-mode grinding: surface grinding / slot grinding / step grinding
  • Rough → Fine → Spark-out automatic cycle

2. High Precision Control (Micron Level)

  • Z-axis precision compensation: ±0.002mm
  • Y-axis precision compensation: ±0.002mm
  • X-axis positioning accuracy: ±0.005mm
  • Fully closed-loop feedback system for stable accuracy

3. Automatic Grinding Functions

  • Automatic wheel down-feed control
  • Adjustable cutting depth and total grinding allowance
  • Automatic wheel dressing system
  • Auto compensation after dressing

4. Intelligent Worktable Movement

  • Automatic reciprocating table movement
  • Adjustable stroke length and speed
  • Supports equal & unequal pitch groove grinding

5. User-Friendly CNC Interface

  • Parameter-based operation (no CNC experience required)
  • Modular HMI screen for easy learning
  • Electronic handwheel for manual axis control
  • Teach-in function for quick setup

6. Heavy-Duty Machine Structure

  • High-grade Meehanite cast iron bed
  • Strong rigidity, long-term deformation resistance
  • Hydraulic-style stable movement structure
  • Designed for continuous industrial operation

CNC System Operation Interface Diagram

Inside Our Manufacturing Facility

Take a closer look at our advanced production lines, precision machining processes, and strict quality control system. Every machine is built with accuracy, stability, and performance in mind.

👉 Get a Quote

Factory Direct Sales

Yutong Manufacturer Direct Supply: CNC Grinding Machines—Better Pricing, Faster Response.
In-house production with strict QC. Stable performance. Reliable delivery.
OEM/ODM supported. Export-ready packing. Get a quote within 24 hours.

Delivery Site

YUTON 4080 PLC surface grinder fully commissioned at customer factory

FAQ

Q: Do you support custom grinding machines?

A: Yes, we provide customized solutions based on your specific requirements, including size, configuration, and application needs.

A: We support flexible order quantities. One unit is acceptable for trial orders.

A: Standard models usually take 15–30 days. Custom machines may require additional time depending on specifications.

A: Our machines can achieve high precision up to ±0.002 mm, ensuring stable and accurate performance.

A: We follow strict quality control processes, including raw material inspection, precision machining, assembly, and final testing.

A: We export to Southeast Asia, Russia, Ukraine, Pakistan, and other international markets.

A: Yes, we offer technical support, operation guidance, and remote assistance to ensure smooth operation.

A: You can contact us with your requirements, and our team will provide a detailed quotation within 24 hours.
